Detinguish Pedestrian And Vehicle Traffic Motion Detector For High Speed Door With Two Realy Output Car Detect Only

Nombre De La Marca:	JUTAI
Número De Modelo:	RVP42-9BW: las condiciones de los productos
MOQ:	Apoyo 1-10 Pcs por muestra
Precio:	Negociable
Detalles Del Embalaje:	50 piezas 1 cartón
Condiciones De Pago:	El pago de las cuotas de pago se realizará en el momento en que el pago de las cuotas de pago se rea

Información detallada

Descripción de producto

Información detallada

Lugar de origen:

China.

Certificación:

CE FCC

Altura de detección:

2.0m-9.0m

Velocidad de detección:

5 cm/s ~ 25km/s

Modo de detección:

Movimiento

Nivel IP:

Operación TEPM:

-30 ℃ ~+60 ℃

Potencia de transmisión:

<20dbm

tecnología:

Radar doppler de microondas

Frecuencia operativa:

24.150 GHz

Voltaje de funcionamiento:

12-36vadc

Corriente operativa:

<100mA

Ajuste de ángulo:

0 ° -90 ° longitudinal

Frecuencia de potencia:

Humedad:

0% a 95% sin condensación

Salida de retransmisión:

24VDC@1A 125vac@0.5a

Área de detección:

3*3.5m-6.5*8.5m (ángulo de 30 °)

Longitud del cable:

7m / personalización

Peso neto:

623 g

Peso bruto:

766 g

Tamaño del producto:

164*111*94 mm

Tamaño del paquete:

275*130*100 mm

Código HS:

903300000090

SERVICIO:

Capacidad de la fuente:

5000 pcs por mes

Resaltar:

industrial door motion detector

high speed door vehicle sensor

traffic detector with relay output

Descripción de producto

Detinguish Pedestrian And Vehicle Traffic Motion Detector For High Speed Door With Two Realy Output Car Detect Only

1. Product-Specific Introduction

The Detinguish Pedestrian and Vehicle Traffic Motion Detector is a purpose-built sensing solution designed exclusively for high-speed door systems, with a core focus on eliminating false triggers and ensuring precise "car detect only" functionality. Equipped with advanced dual-relay outputs, the device delivers targeted control: one relay directly triggers the high-speed door to open/close when a vehicle is detected, while the second relay enables integration with external systems (e.g., access control panels, surveillance alarms) for real-time status feedback. Its proprietary motion analysis technology—combining infrared sensing and pattern recognition—accurately differentiates between vehicles (cars, trucks, forklifts) and pedestrians, even in high-traffic or variable-light environments (e.g., warehouses, loading docks). The detector’s rugged, dust- and water-resistant housing (IP65-rated) ensures durability in industrial settings, while its adjustable detection range (0.5–10 meters) and response time (<0.3 seconds) adapt to diverse high-speed door installation requirements, minimizing door wear and energy waste caused by unnecessary cycles.

2. Application Scenarios & Value

This motion detector is indispensable in environments where high-speed doors require vehicle-only activation to optimize efficiency, safety, and operational cost. Key applications include logistics warehouses and distribution centers, where it prevents high-speed doors from opening for pedestrians—reducing cold/hot air loss in temperature-controlled zones and speeding up vehicle throughput (e.g., delivery trucks, pallet jacks). In manufacturing facilities, it enhances workplace safety by ensuring doors only operate for authorized vehicles, avoiding accidental door closures near pedestrian walkways. It also excels in outdoor parking garages or commercial loading bays, where its weather-resistant design and anti-interference technology (immune to sunlight, rain, or passing debris) maintain reliable performance. By leveraging the dual-relay outputs, users can further integrate the detector with factory automation systems to log door usage, trigger maintenance alerts, or sync with security protocols—creating a streamlined, low-maintenance high-speed door ecosystem centered on vehicle-specific traffic management.

Detinguish Pedestrian And Vehicle Traffic Motion Detector For High Speed Door With Two Realy Output Car Detect Only 0

Detinguish Pedestrian And Vehicle Traffic Motion Detector For High Speed Door With Two Realy Output Car Detect Only 1

Feature

1. Car Detect Only / People Detect Only
- Detection Mechanism: The radar distinguishes between pedestrians and vehicles by analyzing characteristics such as speed, frequency, reflective area, and movement patterns.
- Dual Relays: The radar has two relays that manage pedestrian and vehicle signals separately. Parameters can be set to deactivate one relay, allowing the radar to detect either vehicles only or pedestrians only.
2. Horizontal Filtration
- Detection Area Limitation: By restricting the detection area, the radar effectively filters out interfering signals from other directions, such as objects moving in neighboring areas.
- Lateral Movement Exclusion: The radar will not trigger when pedestrians and vehicles move laterally across the door, reducing the chance of false triggering.
3. Longitudinal Orientation Recognition
- Movement Detection: Similar to horizontal filtration, the radar can recognize the movement of objects in both forward and backward directions.
- Adjustable Functions:
  - A: Detects only forward movement.
  - B: Detects only backward movement.
  - C: Detects both forward and backward movement.
4. Setting by Remote Control or Mobile App
- Remote Control: Allows for quick and responsive setup.
- Mobile App: Offers a simple and intuitive interface, though saving data via Bluetooth may require 30-45 seconds due to transmission delays.
5. Maximum Installation Height Up to 9m
- Installation Range: The radar can be mounted at heights ranging from 2 to 9 meters.
- Recommended Height: For optimal performance and to avoid accidental contact, it is recommended to install the radar at a height of 3 meters or more.
6. Adjustable Detection Area
- Size Adjustment: The detection area can be customized to prevent false triggers and enhance accuracy.
- Levels of Adjustment: Available in small, medium, and large area settings.
7. Easy Integration into Different Systems
- Components: The radar includes a power cable and two relay signal cables for detecting people and cars.
- System Integration: It can be integrated into various systems such as automatic door systems, radar dimming systems, traffic control systems, and security systems, offering flexible application possibilities.

Detinguish Pedestrian And Vehicle Traffic Motion Detector For High Speed Door With Two Realy Output Car Detect Only 2

Setting Reference

Detinguish Pedestrian And Vehicle Traffic Motion Detector For High Speed Door With Two Realy Output Car Detect Only 3

Detinguish Pedestrian And Vehicle Traffic Motion Detector For High Speed Door With Two Realy Output Car Detect Only 4

Production & Package

Detinguish Pedestrian And Vehicle Traffic Motion Detector For High Speed Door With Two Realy Output Car Detect Only 5

Detinguish Pedestrian And Vehicle Traffic Motion Detector For High Speed Door With Two Realy Output Car Detect Only 8

Detinguish Pedestrian And Vehicle Traffic Motion Detector For High Speed Door With Two Realy Output Car Detect Only 11

Certification

Detinguish Pedestrian And Vehicle Traffic Motion Detector For High Speed Door With Two Realy Output Car Detect Only 13

Product Series

RVP42-7ME	RVP42-7BW	RVP42-9ME	RVP42-9BW	RVP42-R
2-7 m Insatallation High Remote setting only	2-7m Installation High Remote Setting Mobile APP Setting	2-9m Installation High Inside Button Setting Remote Setting	2-9m Installation High Inside Button Setting Remote Setting Mobile APP Setting	Radar Remote for All Sensor
Android APP QR Code	iOS system App
Scan the QR Code to Get the Android System APP	Search "GL Control" in iOS App store to get the APP

Detinguish Pedestrian And Vehicle Traffic Motion Detector For High Speed Door With Two Realy Output Car Detect Only 21

Company Profile

JUTAI is a manufacturer of Motion Sensor Photoelectric Sensors, combining research, development, production, sales, and distribution. Our dedication to innovation and quality drives us to provide outstanding solutions for our customers. Besides building our brand, we aim to be a reliable production partner, helping to create and promote your unique brand identity.

With over a decade of experience in research and production, we have gained extensive knowledge in wireless communication technology, automatic door sensors, and the wholesale distribution of barrier gates. Our product range includes automatic door sensors, microwave radar sensors for automatic doors, infrared sensor series, loop detectors, various range wireless RFID card readers, and barrier gates. Each JUTAI hardware product is thoughtfully designed to integrate seamlessly with access control systems, offering comprehensive solutions for access control, parking management, and parking guidance systems.

Detinguish Pedestrian And Vehicle Traffic Motion Detector For High Speed Door With Two Realy Output Car Detect Only 22
